KNOWING YOUR VEHICLE
28
41 F1A0023
SEATS WITH
ADJUSTABLE ARMRESTS
The driver and passenger seats may be
equipped with an armrest that can be
raised and adjusted for height. Operate
the wheel (A) fig. 42 to adjust.
25) 26)
42 F1A0024
SEAT WITH REVOLVING
BASE
(for versions/markets, where provided)
It may be turned through 180° toward
the seat on the opposite side. Operate
the control (A) fig. 43 to turn the seat.
Before turning the seat, it must be
moved forward and only then adjusted
longitudinally fig. 44.
43 F1A0025
44 F1A0026
REVOLVING SEAT WITH
SEAT BELT
(for versions/markets, where provided)
It is equipped with a three-point seat
belt fig. 45, two adjustable armrests (for
their adjustment, see the "Seats with
adjustable armrests" paragraph) and
a head restraint with adjustable height
(adjusting it, see the "head restraints"
paragraph).
27)
45 F1A0027
Backrest angle adjustment
Operate the lever (A) fig. 46.
46 F1A0028
