Fiat Ducato 2021 - Manual Closure of the First Swing; Manual Opening of the First Swing Door from the Inside; Manual Opening of the Second Swing Door; Moving Footboard

25
32 F1A0120
Manual opening of the first swing
door from the inside
(for versions/markets, where provided)
Pull the lever (B) fig. 33 in the direction
indicated by the arrow.
Manual closure of the first swing
door from the outside
Press button on the key with the
remote control. Close the left door first,
followed by the right door.
33 F1A0121
Manual opening of the second
swing door
Pull the lever (C) fig. 34 in the direction
indicated by the arrow.
The double rear swing doors have two
opening positions: the first to an angle
of approximately 90° and the second
is approximately 180°; on some trim
versions/markets 270° opening is also
available. To open the swing doors to
180°, or 270° (for versions/markets
where provided), proceed as follows:
reach the 90° door opening position;
keep pulling the door to press a
force to allow them to open to 180°
or to 270° (for versions/markets where
provided).
34 F1A0122
Electric locking from inside
Close the two rear swing doors (first
left, then right) and press the button (D)
fig. 35 on the electric window control
panel.
35 F1A0761
MOVING FOOTBOARD
(for versions/markets, where provided)
When the side door of the passenger
compartment or luggage compartment
is opened, a footboard emerges from
the lower part of the floorpan fig. 36 to
make it easier to board the vehicle.
17) 18) 19) 20) 21)
5)
36 F1A0119
