Fiat Ducato 2021 - Towing the Vehicle

IN CASE OF EMERGENCY
256
320 F1A0469
once the key has been removed, refit
the lower trim (C) fig. 319, make sure
it locks correctly and fully tighten the
fixing screws (B).
IMPORTANT
81) It is advisable to contact a Fiat
Dealership to have the refitting procedure
carried out. If you would like to proceed
autonomously, special attention must
be paid to the correct coupling of the
retaining clips. Otherwise, noise might be
heard due to an incorrect fastening of the
lower cover with the upper cover.
TOWING THE
VEHICLE
213) 214) 215) 216) 217) 218) 219) 220) 221)
The vehicle is equipped with two rings
for attaching the tow hook.
The front ring is located in the tool box
beneath the passenger side seat.
On versions with Fix&Go kit and
without spare wheel, the tool box
is available only on request for
versions/markets where provided.
In the absence of the tool box the
vehicle front tow hook is housed in the
on-board documentation container,
together with the Owner Handbook.
321 F1A0221
322 F1A0222
323 F1A0344
To use it, proceed as follows:
Open the flap (A) and remove it as
shown in fig. 321;
turn the lock knob (B) fig. 321
anticlockwise and remove it to allow
the compartment fig. 322 to be
removed;
take the screwdriver provided from
the box and prise up at the point
shown to raise the cap (C) fig. 324;
