IN CASE OF EMERGENCY
240
290 F1A0458-1
Optional wired module
291 F1A0455-1
RIGHT CENTRAL PILLAR
OPTIONAL FUSEBOX
(for versions/markets, where provided)
To gain access to the fusebox fig. 292,
remove the protective cover fig. 293.
292 F1A0218
293 F1A0217
WARNING
188)
Never replace a fuse with another
with a higher amp rating; RISK OF FIRE.
If a general protection fuse (MEGA-FUSE,
MIDI-FUSE) is activated, contact a Fiat
Dealership.
189)
Before replacing a fuse, make sure
that the ignition key has been removed
and that all the other services are switched
off and/or disengaged.
190)
If the replaced fuse blows again,
contact a Fiat Dealership.
191)
Contact Fiat Dealership if a safety
system (airbags, brakes), engine system
(engine, transmission) or steering system
general protection fuse blows.
192)
For fuse replacement, contact a Fiat
Dealership.
IMPORTANT
78)
Never replace a faulty fuse with metal
wires or anything else.
