ENGINE COMPARTMENT
FUSEBOX – OPTIONAL WIRING
MODULE
To gain access to the fuse fig. 289
- fig. 290 - fig. 291, remove the
protective cover fig. 288.
288 F1A0334
Proceed as follows:
fully tighten the captive screw using
the dedicated Phillips screwdriver
provided;
slowly rotate the screw anticlockwise
until resistance is encountered (do not
overtighten);
slowly release the screw;
opening is indicated by the entire
screw head coming out of its housing;
remove the cover.
To refit the cover proceed as follows:
join the cover with the box correctly;
fully tighten the captive screw using
the dedicated Phillips screwdriver
provided;
slowly rotate the screw clockwise
until resistance is encountered (do not
overtighten);
slowly release the screw;
closure is indicated by the inset of
the entire screw head in its housing.
Engine compartment fusebox
289 F1A0216
Wired module
(2.2 120 HP / 140 HP / 160 HP / 180
HP H3-Power with AdBlue
®
)
