KNOWING YOUR VEHICLE
68
111 F1A0126
112 F1A0339
CLOSING
Proceed as follows:
hold the bonnet up with one hand
and with the other remove rod (C)
fig. 114 from recess (E) and fit it back
into its catch (D) fig. 113;
lower the bonnet to approximately
20 centimetres from the engine
compartment and let it drop. Make
sure that the bonnet is completely
closed and not only fastened by the
locking device by trying to open it. If it
is not perfectly closed, do not try to
press the bonnet down but open it and
repeat the procedure.
WARNING Always check that the
bonnet is closed correctly to prevent
it from opening while the vehicle is
travelling.
41) 42) 43) 44) 45)
113 F1A0349
114 F1A0129
WARNING
41)
Be very careful not to allow scarves,
neck ties and other loose articles of
clothing from touching, even accidentally,
any moving parts. This may cause the
clothing to be pulled into the part, resulting
in serious risk to the wearer.
42)
For safety reasons, the bonnet must
always be properly closed while driving.
Therefore, make sure that the bonnet
is properly closed and that the lock is
engaged. If you discover that the bonnet
is not perfectly closed while driving, stop
immediately and close the bonnet in the
correct manner.
43)
The bonnet may drop suddenly if the
supporting rod is not positioned correctly.
44)
Perform these operations only when
the vehicle is stationary.
45)
Use both hands to lift the bonnet.
Before lifting, check that the windscreen
wiper arms are not raised from the
windscreen, that the vehicle is stationary
and that the parking brake is engaged.
