WEIGHTS AND
LOADS
To identify the weights and loads
for your vehicle, refer to the plate
shown in fig. 345 and described in the
“Vehicle identification number (VIN)
plate" chapter or refer to the vehicle
registration certificate showing the
type-approved weights (for markets,
where provided).
345 F1A0245
E Maximum permitted weight of fully
laden vehicle (GVW).
F Maximum permitted weight of the
vehicle (GVW) fully laden plus trailer.
If there is no value in the field or if
there is a dash, it means that the
vehicle cannot tow
G Maximum permitted weight on first
axle (front).
H Maximum permitted weight on
second axle (rear).
To calculate the towable weight with
a braked trailer, take the difference
between values F and E shown on the
plate.
E.g.: F=6000 kg - E=3500 kg
Braked trailer=2500 kg
IMPORTANT
Do not exceed the
indicated trailer and towable weights.
IMPORTANT
Comply with the vehicle
towing capacities.
The tables show the towable weight for
engine version.
