KNOWING YOUR VEHICLE
32
57 F1A0035
– turn the backrest 5° towards the rear
area;
– fold the backrest forward with your
left hand.
30)
58 F1A0036
Removing the bench
Undo the screws (A) and (B) fig. 59;
59 F1A0710
remove the plastic casing of the
benches fig. 60;
60 F1A0711
undo the screws (C) and (D) and
remove the heater cover fig. 61;
61 F1A0712
disconnect the connector fig. 62;
62 F1A0713
lift the lever (A), tilt the backrest
forward into the Easy Entry position
and pull out the head restraints fig. 63;
