AN6000 Series Optical Line Terminal Equipment Hardware Description
Width: The height of the
reed is not counted.
Depth: The maximum distance between the panel and the
connector.
Figure 5-2 Card Dimensions
Table 5-1 describes card dimensions.
Table 5-1 Card Dimensions
Card Type
Card
Dimensions (H × W × D)
Core switch card HSCA
392 mm × 29.7 mm × 230.6
mm
Uplink card
HU8A, KU1B
392 mm × 23 mm × 230.6 mm
Power card PIBA 98 mm × 25.1 mm × 255.5 mm
Service card
EX8A, EXOA, GPOA, GX8A, GM8A,
GM8B, GMOA, GNOA, GFOA,
PXNA
392 mm × 23 mm × 230.6 mm
Common interface
card
CIOA
194 mm × 25.1 mm × 230.6
mm
26
Version: B
