SECTION 2 – DESIGN
UL / ULC Ex4623 Fike Clean Agent System w/ FM-200™ Page 11 of 39
FM 3010715 Manual P/N: 06-215 (Rev G) Revision Date: January. 2010
2.6 CONTAINER SELECTION
Generally, the selection of containers is determined by the amount of HFC-227ea required vs. the approved fill
ranges for the various container sizes. However, additional factors such as the System Design Concept,
container storage location, and flow calculation limitations may have an impact on this decision as well.
2.6.1 CONTAINER SIZE AND FILL RANGE
All containers must be filled within the allowable fill range mandated by DOT and UL Standard 2166. The
acceptable fill range for these containers is based upon a minimum fill density of 40 lbs./ft
3
(640 kg/m
3
) of
container volume, to a maximum of 70 lbs./ft
3
(1121 kg/m
3
), in 1 lb. (0.5 kg) increments.
PRE-ENGINEERED CONTAINER DATA TABLE
Container Size
Container
Part Number
Minimum Fill lbs.
(kg)
Maximum Fill lbs.
(kg)
Mounting Position
35 lb. (15 L) 70-089 (T) 22 lbs. (10.0 kg) 38 lbs. (17.0 kg) Upright - Horizontal
60 lb. (27 L) 70-152 (T) 39 lbs. (18.0 kg) 68 lbs. (30.5 kg) Upright - Horizontal
100 lb. (44 L) 70-153 (T) 63 lbs. (28.5 kg) 108 lbs. (48.5 kg) Upright - Horizontal
125 lb. (51 L) 70-041 (T) 73 lbs. (33.5 kg) 126 lbs. (57 kg) Inverted – Valve Down
215 lb. (90 L) 70-077 (T) 128 lbs. (58.5 kg) 223 lbs. (101 kg) Inverted – Valve Down
215 lb. (87 L) 70-154 (T) 124 lbs. (56.5 kg) 216 lbs. (98.0 kg) Upright – Floor Mount
375 lb. (153 L) 70-155 (T) 217 lbs. (98.5 kg) 378 lbs. (171.5 kg) Upright – Floor Mount
650 lb. (267 L) 70-156 (T) 378 lbs. (171.5 kg) 660 lbs. (299.0kg) Upright – Floor Mount
1000 lb. (423 L) 70-157 (T) 578 lbs. (271.5 kg) 1,045 lbs. (474.0 kg) Upright – Floor Mount
ENGINEERED CONTAINER DATA TABLE
Container Size
Container
Part Number
Minimum Fill lbs.
(kg)
Maximum Fill lbs.
(kg)
Mounting Position
20 lb. (8.5 L) 70-098 (T) 12 lbs. (5.5 kg) 21 lbs. (9.5 kg) Upright - Horizontal
35 lb. (15 L) 70-089 (T) 22 lbs. (10.0 kg) 38 lbs. (17.0 kg) Upright - Horizontal
60 lb. (27 L) 70-152 (T) 39 lbs. (18.0 kg) 68 lbs. (30.5 kg) Upright - Horizontal
100 lb. (44 L) 70-153 (T) 63 lbs. (28.5 kg) 108 lbs. (48.5 kg) Upright - Horizontal
125 lb. (51 L) 70-041 (T) 73 lbs. (33.5 kg) 126 lbs. (57 kg) Inverted – Valve Down
215 lb. (90 L) 70-077 (T) 128 lbs. (58.5 kg) 223 lbs. (101 kg) Inverted – Valve Down
215 lb. (87 L) 70-154 (T) 124 lbs. (56.5 kg) 216 lbs. (98.0 kg) Upright – Floor Mount
375 lb. (153 L) 70-155 (T) 217 lbs. (98.5 kg) 378 lbs. (171.5 kg) Upright – Floor Mount
650 lb. (267 L) 70-156 (T) 378 lbs. (171.5 kg) 660 lbs. (299.0kg) Upright – Floor Mount
1000 lb. (423 L) 70-157 (T) 578 lbs. (271.5 kg) 1,045 lbs. (474.0 kg) Upright – Floor Mount
(T) = Container part number with the suffix T indicates container with threaded valve.
