SECTION 2 – DESIGN
UL / ULC Ex4623 Fike Clean Agent System w/ FM-200™ Page 27 of 39
FM 3010715 Manual P/N: 06-215 (Rev G) Revision Date: January. 2010
r
v
t
i
CHECK VALVE
s
CE
EE
EL
CE
EL
CE
3" (76 mm)
3" (76 mm)
30" (762 mm)
CHECK VALVE
THREADED MANIFOLD
(NOT RECOMMENDED FOR LARGER THAN 3” NPT (80 mm)
END EXIT MANIFOLD / 3” THRU 6” (80 mm thru 150 mm)
