Description
3.3 Housing
A5850-02en Edition 06/2022 25
• Oil filling point for refilling with oil
• Oil level indicator or dipstick for checking the oil level
• Oil drain screw or oil drain valve for changing the oil
• Air filter or wet-air filter for ventilation and bleeding
Further information
You can find additional information and a detailed illustration of the gear unit and the position
of the mounted components in the dimension drawings in the complete documentation for
the gear unit.
The diagram below shows the available gear unit equipment on gear units of type K..H:
Figure3-2:Gear unit equipment on gear units of type K..H
① Lifting eye ⑥ Cover
② Cover ⑦ Shaft seal
③ Housing ⑧ Rating plate
④ Inspection cover ⑨ Gear unit fastening
⑤ Alignment surface ⑩ Alignment thread
