3.7 Cooling
A5850-02en Edition 06/2022 35
Information
Observe the flow direction of the pump
When connecting the valves, observe the flow direction of the pump.
Refer to the pump operating instructions in the complete gear unit documentation to ascer-
tain whether the flow direction of the pump used depends on the direction of rotation.
Further information
You can find additional information about the oil supply system in the separate data sheet, in
the list of equipment and in the oil supply system operating instructions provided in the com-
plete gear unit documentation.
You can find additional information and a detailed illustrated description of the gear unit and
the oil supply system in the dimension drawing in the complete gear unit documentation.
3.7.3.1 Pump3.7 Cooling
Requirements placed on the medium being pumped
The pump being used is suitable for pumping lubricating oil. It is not permissible that the oil
contains abrasive components and must not chemically attack the materials used in the
pump. Clean oil with good lubricating properties is a precondition for ensuring the correct
function, high operational reliability and long service life of the pump.
3.7.3.2 Oil filter3.7 Cooling
Introduction
The oil filter protects downstream units, measuring and control devices against dirt and pollu-
tion.
Principle of operation
The oil filter comprises a housing with connections and a filter cartridge. The medium flows
through the filter housing, where, depending on the filter gauge, most of the dirt particles lar-
ger than a defined size in the oil are filtered out. Dirty filter cartridges must be cleaned or re-
placed.
3.7.3.3 Pressure monitor3.7 Cooling
The pressure of the mounted oil supply system is monitored using a pressure monitor.
Further information
You can find additional information on the pressure monitor in the pressure monitor operat-
ing instructions provided in the complete gear unit documentation.
You can find additional technical data in the separate data sheet and in the list of equipment
provided in the complete gear unit documentation.
