A5850-02en Edition 06/2022 43
Application planning
4
4.1 Scope of delivery4.1 Scope of delivery
The scope of delivery is listed in the shipping documents. Immediately upon receiving the
gearbox, check that everything has been delivered. Report any damaged and/or missing
parts to Customer Services (Page95) immediately.
WARNING
Serious injury through defective product
Serious injury may occur.
If the gearbox exhibits any visible damage, you should not put it into operation.
4.2 Transport4.2 Transport
General information
The gear unit is delivered fully assembled. Additional items such as shrink disks, couplings,
oil coolers, pipework and valves may be delivered separately packaged, as necessary.
When transporting the gear unit, observe the following instructions to avoid damaging the
gear unit:
• Always use suitable equipment to transport the gear unit.
• Transport the gear unit without oil filling and leave it in the transport packaging.
• Do not use incorrect attachment points.
The threads in the end faces of the shaft ends may not be used for attaching lifting equip-
ment.
• Do not use the pipework to move the gear unit.
• Ensure that the lifting equipment is adequately designed to accommodate the weight of
the gear unit.
• Always set the gear unit down onto a suitable base.
The base must be designed such that there is no risk of damage to the gear unit or its
mounted components.
WARNING
Risk of crushing
There is a risk of being crushed by a component that becomes detached because the
hoisting gear and load suspension device are not suitable for handling it.
When lifting, please observe the load distribution information on the packaging.
When the product is in a raised position, transport it slowly and carefully to avoid injury to
persons or damage to the gear unit.
