5.3 Gear unit assembly
52 Edition 06/2022 A5850-02en
5.3.2 Description of assembly work5.3 Gear unit assembly
CAUTION
Risk of chemical burns from chemical substances
There is a risk of chemical burns when handling aggressive cleaning agents.
Please observe the manufacturer’s instructions on how to handle cleaning agents and
solvents. Wear suitable protective equipment (gloves, safety glasses). Remove any spilled
solvent immediately with binding agents.
CAUTION
Risk of injury due to chemically aggressive operating materials
There is a risk of injury to eyes and hands when handling chemically corrosive consum-
ables.
Please observe the safety information in the data sheets of the oil used. Wear suitable pro-
tective equipment (gloves, safety glasses). Immediately clean up any spilt oil using a bind-
ing agent.
Improper use can damage the gear unit. Take the following precautions:
• Use a suitable cleaning agent to remove the corrosion protection from the shafts and ad-
joining mounting surfaces.
• Do not allow the cleaning agent to come into contact with the shaft sealing rings.
• Mount the input and output elements (e.g. coupling parts) on the shafts and lock them
securely. See chapter Couplings (Page69).
• Use suitable hoisting gear to place the gear unit in position.
More information
Further information about removing the corrosion protection can be found in the instruc-
tions7300 in the complete documentation for the gear unit.
You can find more information on attaching gear units to hoisting gear in cases where the
weight of the gear unit necessitates the use of hoisting gear in chapter Application planning
(Page43).
If the gear unit is to be transported with mounted parts and components, then it may be ne-
cessary to use additional attachment points. You will find the position of these attachment
points in the order-specific dimension drawing, which is part of the complete documentation
of the gear unit.
