FLENDER K.SH - Tacolab Seal; Table 3-2 Taconite Seal Versions

Description
3.6 Shaft seal
30 Edition 06/2022 A5850-02en
Taconite seal versions Application Remarks
"F-H" Output shaft
Design H: Hollow shaft with parallel keyway
Design K: Hollow shaft with spline according to
DIN5480
• Regreasable labyrinth on the output side,
dust-proof protection cover on the oppos-
ite side
"F-K" Output shaft
Design D: Hollow shaft for shrink disk
Table3-2: Taconite seal versions
NOTICE
Sparking, inadmissible temperature rise and shaft seal wear due to insufficient gap
dimension
An insufficient gap dimension can cause sparking, inadmissible temperature rise and shaft
seal wear.
If the shaft is sealed by Taconite seals, ensure that the set gap dimension of 1
+0.5
mm on
the grease labyrinth is not changed when the input and output elements (e.g. coupling
parts) are mounted. Rotating and stationary parts must not touch.
3.6.4 Tacolab seal3.6 Shaft seal
Applications
Tacolab seals can only be used for certain gear ratios and minimum speeds.
Features
Tacolab seals are non-contact, low-maintenance seals that do not wear. It is not therefore
necessary to interrupt operation in order to service or replace them.
The Tacolab seal is a combination of two sealing elements:
• Labyrinth seal comprising two labyrinth sealing rings to prevent the escape of lubricating
oil
• Grease-filled dust seal (comprising a labyrinth and a lamellar seal) to allow operation of
the gear unit in extremely dusty environments
