Assembly
5.5 Connecting components
A5850-02en Edition 06/2022 75
5.5.6 Electrical connections5.5 Connecting components
Procedure
DANGER
Electric shock
Live parts can cause electric shock.
Ensure that the entire plant is de-energised before starting electrical installation work.
Carefully observe the five safety rules (Page15).
To connect the motors and monitoring devices, proceed as follows:
1. Ensure that the connections of the motors and monitoring devices are not damaged.
2. Connect the motors and monitoring devices according to the terminal diagram.
Further information
You can find additional information about the electrical connections in the terminal diagrams
and equipment lists provided in the complete gear unit documentation.
5.6 Tightening procedure5.6 Tightening procedure
5.6.1 Introduction5.6 Tightening procedure
Bolts
The bolts must have the following properties:
• Made of steel
• Black-annealed or phosphatised
• Lightly oiled (do not add additional oil)
Information
Replacing bolts
Replace any bolts that are no longer fit for use by bolts of the same type and strength class.
Mating threads
The mating threads must have the following properties:
• Made of steel or cast iron
• Dry, cut threads
