Application planning
4.4 Special aspects of gear unit lubrication and preservation
A5850-02en Edition 06/2022 47
4.4 Special aspects of gear unit lubrication and preservation4.4 Special aspects of gear unit lubrication and preservation
4.4.1 Oil filling point and oil drain4.4 Special aspects of gear unit lubrication and preservation
The following diagram shows the oil filling point and the oil drain on the gear unit:





Figure4-5:Oil filling point and oil drain
① Oil level indicator ④ Oil filling point
② Oil dipstick ⑤ Venting point
③ Inspection cover ⑥ Oil drain screws
Further information
You can find additional information and a detailed illustration of the gear unit and the position
of the mounted components in the dimension drawings in the complete documentation for
the gear unit.
