5.5 Connecting components
A5850-02en Edition 06/2022 73
5.5 Connecting components5.5 Connecting components
5.5.1 Gear units with mounted components5.5 Connecting components
Depending on the order specification, the gear unit can be equipped with various compon-
ents.
Connect the closed-loop control and open-loop control electrical devices corresponding to
the specifications of the device supplier.
Further information
You can find additional information on operation and maintenance in the associated operat-
ing instructions, provided in the complete gear unit documentation.
You can find the technical data of the mounted components in the contract-list of equipment
provided in the complete gear unit documentation.
5.5.2 Connecting the cooling coil5.5 Connecting components
Procedure
To connect the cooling coil to the gear unit, proceed as follows:
1. Before connecting the cooling coil, remove the sealing plugs from the connection
sleeves.
2. Flush through the cooling coil to remove any dirt or dust.
3. Connect up the cooling water inlet and drain lines. Refer to the dimension drawing for
the position of the connections.
Further information
You can find additional about the cooling coil in the complete documentation for the gear
unit.
Information
Observe the information provided in chapter Cooling coils (Page33).
5.5.3 Installing a separate oil supply system5.5 Connecting components
Procedure
To connect the oil supply system to the gear unit, proceed as follows:
1. Remove the dummy flange from the suction and delivery line before connecting the sys-
tem.
