5700A/5720A Series II
Operators Manual
4-18
B.
A.
UUT
HI
LO
A
HI
LO
GUARD
INPUT
SENSE
4-WIRE
HI
HI
LO
LO
HI
SENSE
V
AUX
CURRENT
V-GUARD
GROUND
WIDEBAND
NOTE
Keep the SENSE leads as short as possible.
Be careful not to exceed the capacitive load limit of 1000 pF up to 220V,
600 pF 220 to 1100V. (1000 pF with 5725A Amplifier.)
TRIAXIAL CABLE
UUT
HI
LO
A
HI
LO
GUARD
INPUT
SENSE
4-WIRE
HI
HI
LO
LO
HI
SENSE
V
AUX
CURRENT
V-GUARD
GROUND
WIDEBAND
TRIAXIAL CABLE
TRIAXIAL CABLE
EX SNS
: OFF
EX GRD
: OFF
EX SNS
: ON
EX GRD
: OFF
OUTPUT
V A
OUTPUT
V A
CALIBRATOR
CALIBRATOR
Figure 4-2. UUT Connections: AC Voltage >10 kHz
