Table 5-1. Command Summary by Function (continued)
Output Commands
BOOST Activates or deactivates an auxiliary amplifier
DBMOUT? Returns the output amplitude and frequency, but in dBm if ac V
OPER Activates the calibrator’s output if it is in standby
OUT Sets the output and establishes a new reference for error mode
OUT? Returns the output amplitude and frequency
PHASE Sets the phase shift of the phase output signal
PHASE? Returns the phase shift of the phase output signal
PHASELCK Activates or deactivates phase locking to an external signal
PHASESFT Activates or deactivates variable phase output
RCOMP Activates or deactivates two-wire compensation circuitry
STBY Puts the calibrator in standby
VOUT? Returns the output amplitude in volts if the active units are dBm
WBAND Activates or deactivates the Wideband AC Module (Option 5700A-03)
Overall Functions
*CLS Clear; clears status registers, any service request, and flags
ECHO? Echoes a string to the remote port
GAL Go to Alternate Language; enters Fluke 5100B emulation mode
*OPC Sets bit 0 in the ESR to 1 when pending remote operations are complete
*OPC? Returns a "1" when all pending remote operations are complete
*PUD Stores a string of user-selected characters in nonvolatile memory
*PUD? Returns the contents of the PUD memory
RPT_STR Loads the user report string
RPT_STR? Returns the user report string
*RST Reset; sets the calibrator to its default power-up state
*WAI Halts remote program execution until all pending remote operations are
complete

Fluke 5700A Series II Specifications

General

Type	Multifunction Calibrator
Operating Temperature	0 °C to 50 °C
Storage Temperature	-20 °C to 70 °C
Voltage Range	0 to 1100 V
DC Voltage Range	10 μV to 1100 V
Frequency Range	1 MHz
Humidity	non-condensing
Power Requirements	100 V to 240 V
