Important The 2nd position x defines the exact network point for the
following status messages:
0 = several / all 3 phases
1= L1
2= L2
3= L3
1x2
AC voltage too high
Behavior Grid conditions are thoroughly tested and as soon as
they are again within the permissible range, the Froni-
us IG Plus will resume feeding power into the grid.
Remedy Check grid connections and fuses
If this status message keeps recurring, contact your
system installer
1x3
AC voltage too low
Behavior Grid conditions are thoroughly tested and as soon as
they are again within the permissible range, the Froni-
us IG Plus will resume feeding power into the grid.
Remedy Check grid connections and fuses
If this status message keeps recurring, contact your
system installer
1x5
AC frequency too high
Behavior Grid conditions are thoroughly tested and as soon as
they are again within the permissible range, the Froni-
us IG Plus will resume feeding power into the grid.
Remedy Check grid connections and fuses
If this status message keeps recurring, contact your
system installer
1x6
AC frequency too low
Behavior Grid conditions are thoroughly tested and as soon as
they are again within the permissible range, the Froni-
us IG Plus will resume feeding power into the grid.
Remedy Check grid connections and fuses
If this status message keeps recurring, contact your
system installer
Class 1 Status
Codes
(continued)

Fronius IG Plus 3.0-1 Specifications

General

Protection class	IP 44
Max. output current	13 A
Nominal AC voltage	230 V
THD	< 3%
Max. DC voltage	500 V
Maximum Input Voltage	500 V
Number of MPP Trackers	1
Operating Temperature Range	-20°C to +55°C
Cooling	Convection
Warranty	5 years
AC nominal output	3000 W
Max. apparent AC power	3000 VA
AC voltage range	180 - 264 V
