43
Fuse Recom-
mendations -
Application
Example
NOTE
Only select fuses suitable for a voltage of 600 V DC.
Example:
Maximum short circuit current (I
SC
) of the solar module = 5.75 A
According to the criteria for selecting the correct fuse, the fuse must have
a nominal current greater than 1.5 times the short circuit current:
5.75 A x 1.56 = 8.97 A
The fuse that should be selected according to the ‘Fuses’ table: KLK D 9
with 9.0 A and 600 V AC / DC
Nominal Fuse
current value
1.0 A KLK D 1
1.5 A KLK D 1
1
/
2
2.0 A KLK D 2
2.5 A KLK D 2
1
/
2
3.0 A KLK D 3
3.5 A KLK D 3
1
/
2
4.0 A KLK D 4
5.0 A KLK D 5
Fuses
‘Fuses’ table: Excerpt of suitable fuses, e.g. Littelfuse fuses
Nominal Fuse
current value
6.0 A KLK D 6
7.0 A KLK D 7
8.0 A KLK D 8
9.0 A KLK D 9
10.0 A KLK D 10
12.0 A KLK D 12
15.0 A KLK D 15
20.0 A KLK D 20

Fronius IG Plus 3.0-1 Specifications

General

Protection class	IP 44
Max. output current	13 A
Nominal AC voltage	230 V
THD	< 3%
Max. DC voltage	500 V
Maximum Input Voltage	500 V
Number of MPP Trackers	1
Operating Temperature Range	-20°C to +55°C
Cooling	Convection
Warranty	5 years
AC nominal output	3000 W
Max. apparent AC power	3000 VA
AC voltage range	180 - 264 V
