Fronius IG Plus 3.0-1 User Manual

10
FCC Compli-
ance
This device complies with Part 15 of the FCC Rules. Operation
is subject to the following conditions:
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received, including
interference that may cause undesired operation.
Ground Fault
Detector /
Interruptor
Your Fronius IG Plus unit complies with the requirements for the following
standards "Inverters, converters and controllers for use in independent
power systems":
- UL1741-2005
- IEEE 1547-2003
- IEEE 1547.1
- ANSI / IEEE C62.41
- C22.2 No. 107.1-01 (Sep. 2001)
The ground-fault detection and interruption is in compliance with NEC 690
building code requirements.
The respective conformity declarations can be found in the appendix to
these operating instructions.
Standards and
Regulations
Product lis-
tings and
compliance
The Fronius IG Plus unit is provided with field adjustable trip points. For
further information please contact Fronius technical support E-Mail: pv-us-
support@fronius.com.
Information
for Field adju-
stable trip
points
Monitoring the
grid
(continued)
Your Fronius IG Plus unit determines the grid’s status by:
- monitoring voltage
- monitoring frequency
- monitoring islanding conditions
The Fronius IG Plus is equipped with a ground fault detection and inter-
ruption (GFDI) circuit as required by UL 1741 and the National Electrical
code.
Depending on the system configuration either the PV array’s negative or
positive conductor is connected to the grounding system in the inverter. If
a ground fault occurs in the DC wiring, the inverter disconnects from the
grid.

Fronius IG Plus 3.0-1 Specifications

General

Protection class	IP 44
Max. output current	13 A
Nominal AC voltage	230 V
THD	< 3%
Max. DC voltage	500 V
Maximum Input Voltage	500 V
Number of MPP Trackers	1
Operating Temperature Range	-20°C to +55°C
Cooling	Convection
Warranty	5 years
AC nominal output	3000 W
Max. apparent AC power	3000 VA
AC voltage range	180 - 264 V
