Fronius IG Plus 3.0-1 User Manual

24
NEMA 3R protection means that the Fronius IG Plus can be exposed to
moisture. However, we recommend that direct moisture and direct water
spray such as a sprinkler be avoided, if possible.
In order to protect the display, the Fronius IG Plus should not be exposed
to direct sunlight. Ideally, the Fronius IG Plus should be installed in a
protected location, e.g. near the solar modules or under a roof overhang.
Choosing a
Location for
Outside Instal-
lation

Fronius IG Plus 3.0-1 Specifications

General

Protection class	IP 44
Max. output current	13 A
Nominal AC voltage	230 V
THD	< 3%
Max. DC voltage	500 V
Maximum Input Voltage	500 V
Number of MPP Trackers	1
Operating Temperature Range	-20°C to +55°C
Cooling	Convection
Warranty	5 years
AC nominal output	3000 W
Max. apparent AC power	3000 VA
AC voltage range	180 - 264 V
