Fronius IG Plus 3.0-1 User Manual

IMPORTANT SAFETY
INSTRUCTIONS
SAVE THESE INSTRUCTIONS
General This manual contains important instructions for the Fronius IG Plus, that
must be followed during installation and maintenance of the inverter.
The Fronius IG Plus is designed and tested according to international
safety requirements, but as with all electrical and electronic equipment,
certain precautions must be observed when installing and/or operating the
Fronius IG Plus.
To reduce the risk of personal injury and to ensure the safe installation
and operation of the Fronius IG Plus, you must carefully read and follow
all instructions and safety instructions in this manual.
Safety Instruc-
tions
The following section “Safety Instructions“ contains different Warnings. A
Warning describes a hazard to equipment or personnel. It calls attention
to a procedure or practice, which, if not correctly performed or adhered to,
could result in damage to or destruction of part or all of the Fronius inver-
ter and/or other equipment connected to the Fronius inverter or personal
injury.
All electrical installations must be made in accordance with the National
Electrical Code, ANSI/NFPA 70, and any other codes and regulations
applicable to the installation site.
For installations in Canada the installations must be done in accordance
with applicable Canadian standards.
Electrical
installations

Fronius IG Plus 3.0-1 Specifications

General

Protection class	IP 44
Max. output current	13 A
Nominal AC voltage	230 V
THD	< 3%
Max. DC voltage	500 V
Maximum Input Voltage	500 V
Number of MPP Trackers	1
Operating Temperature Range	-20°C to +55°C
Cooling	Convection
Warranty	5 years
AC nominal output	3000 W
Max. apparent AC power	3000 VA
AC voltage range	180 - 264 V
