Displaying the welding circuit Inductivity L
General The way that the hosepack is arranged has a very significant effect on the weld-
ing circuit inductivity and therefore affects the welding process. It is important
to lay the hosepacks correctly in order to obtain the best possible welding result.
Displaying the
welding circuit
inductivity
The setup parameter "L" is used to display the most recently calculated welding
circuit inductivity. The welding circuit inductivity is adjusted when the welding
circuit resistance is measured. Detailed information in this regard can be found
under the "Welding circuit resistance" chapter.
1
Access the Setup menu 2nd level (2nd)
2
Select parameter "L"
The most recently calculated welding circuit inductivity L is shown on the right-
hand digital display.
L ... Welding circuit inductivity (in microhenrys)
Laying the
hosepacks cor-
rectly
