MIG/MAG synergic welding
MIG/MAG syner-
gic welding
1
Press the "Material" button to select the filler metal to be used.
2
Press the "Wire diameter" button to select the diameter of the wire electrode
used.
3
Press the "Shielding gas" button to select the shielding gas to be used.
The assignment of the SP position is in the welding program tables in the ap-
pendix.
4
Press the "Process" button to select the desired welding process:
MIG/MAG standard synergic welding
MIG/MAG pulsed synergic welding
5
Press the "Mode" button to select the desired MIG/MAG mode:
2-step mode
4-step mode
Special 4-step mode
IMPORTANT! Under certain circumstances, it may not be possible to change
welding parameters that have been set on the control panel of a system compon-
ent - such as remote control or wirefeeder - on the control panel of the power
source.
68
