TransSteel 5000
Pulse MV nc
Mains voltage (U
1
) 3 x 200 V / 230 V / 400 V / 460 V
Max. effective primary current (I
1eff
)
3 x 200 V 39.5 A
3 x 230 V 36.3 A
3 x 400 V 20.6 A
3 x 460 V 18.1 A
Max. primary current (I
1max
)
3 x 200 V 66.7 A
3 x 230 V 57.4 A
3 x 400 V 32.5 A
3 x 460 V 28.6 A
Mains fuse
3 x 200 V / 230 V 63 A slow-blow
3 x 400 V / 460 V 35 A slow-blow
Mains voltage tolerance -10 / +15%
Mains frequency 50/60 Hz
Cos phi (1) 0.99
Max. permitted grid impedance Z
max
on PCC
1)
52.2 mOhm
Recommended residual-current cir-
cuit breaker
Type B
Welding current range (I
2
)
MIG/MAG 10 - 500 A
MMA 10 - 500 A
Welding current at 10 min / 40 °C
(104 °F)
U
1
: 200 V 35% / 500 A
60% / 420 A
100% / 360 A
U
1
: 208 - 460 V 40% / 500 A
60% / 420 A
100% / 360 A
Output voltage range according to
standard characteristic (U
2
)
MIG/MAG 14.3 - 39 V
MMA 20.2 - 40 V
Open circuit voltage
(U
0
peak / U
0
r.m.s)
57 V
Apparent power
at 200 V AC / 500 A / 40% ED
2)
23.08 kVA
at 400 V AC / 500 A / 40% ED
2)
22.49 kVA
132
