Connecting the Mains Cable
General If no mains cable is connected, a mains cable that is suitable for the connection
voltage must be fitted before commissioning.
A strain-relief device for the following cable cross-sections is fitted to the power
source:
Power source Cable cross-section
Fitted strain-relief device
for
Canada/US
Europe
TransSteel 4000 Pulse AWG 12 *) 4G2.5
TransSteel 5000 Pulse AWG 10 *) 4G4
TransSteel 4000 MV
Pulse
AWG 10 *) 4G4
TransSteel 5000 MV
Pulse
AWG 6 *) 4G10
*) Canada / US cable type: Extra-hard usage
Strain-relief devices for other cable cross-sections must be designed accord-
ingly.
Stipulated mains
cables and
strain-relief
devices
Power source Grid voltage Cable cross-sec-
tion
Canada / US
Europe
TransSteel 4000
Pulse
3 x 380 / 400 V AWG 12 *) 4G2.5
3 x 460 V AWG 12 *) 4G2.5
TransSteel 5000
Pulse
3 x 380 / 400 V AWG 8 *) 4G4
3 x 460 V AWG 10 *) 4G4
TransSteel 4000 MV
Pulse
3 x 208 / 230 / 400 /460
V
AWG 10 *) 4G4
TransSteel 5000 MV
Pulse
3 x 208 / 230 / 400 /
460 V
AWG 6 *) 4G10
*) Canada / US cable type: Extra-hard usage
The item numbers of the different cables can be found in the Spare Parts List for
the devices.
AWG ... American Wire Gauge
46
