Safety
WARNING!
Danger from work that is not carried out properly.
This can result in severe personal injury and damage to property.
▶
The work described below may only be performed by trained specialist per-
sonnel.
▶
Follow national standards and guidelines.
CAUTION!
Danger from improperly prepared mains cable.
Short circuits and damage to property may result.
▶
Fit ferrules to all phase conductors and the ground conductor of the
stripped mains cable.
Connecting the
mains cable
If no mains cable is connected, a mains cable that is suitable for the connection
voltage must be fitted before commissioning.
The ground conductor should be approx. 10 - 15 mm (0.4 - 0.6 in.) longer than
the phase conductors.
A graphic representation of the mains cable connection is provided in the sec-
tions "Fitting the strain-relief device" or "Fitting the strain-relief device for
Canada / US." To connect the mains cable, proceed as follows:
1
Remove the side panel of the device
2
Push in the mains cable so that the ground conductor and phase conductor
can be properly connected to the block terminal.
3
Fit a ferrule to the ground conductor and phase conductor
4
Connect the ground conductor and phase conductor to the block terminal
5
Secure the mains cable with a strain-relief device
6
Fit the side panel of the device
