NOTE!
The Ito function (length of wire fed until safety cut-out trips) is a safety func-
tion.
At high wire speeds in particular, the length of wire fed until the safety cut-out
trips can deviate from the set wire length.
SPt Spot welding time / interval welding time
Unit: s
Setting range: 0.3 - 5
Factory setting: 1
SPb Interval pause time
Unit: s
Setting range: OFF, 0.3 - 10 (in 0.1 s increments)
Factory setting: OFF
IMPORTANT! SPb = OFF must be set for spot welding!
Int Interval
Displayed only if a value has been set for SPb
Unit:
Setting range: 2T (2-step), 4T (4-step)
Factory setting: 2T (2-step)
F Frequency for SynchroPulse
Unit: Hz
Setting range: OFF, 0.5 - 5
Factory setting: OFF
dFd Delta wire feed
Offset welding power for SynchroPulse option
Unit: m/min (ipm)
Setting range: 0 - 3 (0 - 118.1)
Factory setting: 2 (78.7)
AL2 Arc length correction for upper SynchroPulse operating point
Unit: % (of welding power)
Setting range: 30 - +30
Factory setting: 0
FAC Reset power source to factory settings
Press and hold one of the "Parameter selection" buttons for two seconds
to restore the factory settings
- when "PrG" appears on the digital display, the power source has been re-
set
IMPORTANT! If the power source is reset, all the personal settings in the
Setup menu are lost.
Operating points stored using save buttons remain stored when the power
source is reset. The functions in the second level of the setup menu (2nd)
are also not deleted. Exception: Ignition time-out function parameter (ito).
2nd Second level of the Setup menu (see "Setup Menu 2nd Level")
97
EN-US
