Fuji Electric FRENIC MEGA G2 Series - 1 ] PID Command with Keypad (J02 = 0, Factory Default)

5.3 Description of Function Codes 5.3.8 J codes (Applied functions)
5-268
・Using J01 allows switching between normal and inverse operations for the PID control output, so you can specify
an increase/decrease of the motor rotating speed depending on the difference (error component) between the
commanded (input) and feedback amounts, making it possible to apply the inverter to air conditioners. The
terminal command IVS can also switch operation between normal and inverse.
 For details about the switching of normal/inverse operation, refer to the description of “■ Normal/inverse
operation switching “IVS” assignment” (E01 to E09, data = 21).
J02
PID control (remote command)
Related function codes J105: PID control (Display unit)
J106: PID control (Maximum scale)
J107: PID control (Minimum scale)
J136 to J138: PID control multistep command 1 to 3
J02 sets the source that specifies the command value (SV) under PID control.
J02 data
Function
0
PID command with keypad
PID command with keypad / keys
1
PID command 1 (Analog input: Terminals [12], [V2], [C1] (C1 function), [C1] (V3 function))
Voltage input to terminal [12], [V2], [C1] (V3 function) (0 to ±10 VDC, 100% PID
command/±10 VDC)
Current input to terminal [C1] (C1 function) (4 to 20 mA DC, 100% PID command/20 mA DC)
3
Terminal command UP/DOWN
Using the “UP” or “DOWN” command in conjunction with PID minimum scale to maximum
scale (specified by J106 and J107) with which the command value is converted into a
physical quantity, etc., you can specify 0 to 100 % of the PID command (± 100% for PID
dancer control).
4
Command via communications link
Use function code S13 to specify the PID command by communications. The transmission
data of 20000d (decimal) is equal to 100% (maximum set point value) of the PID command.
[ 1 ] PID command with keypad (J02 = 0, factory default)
Using the / keys on the keypad in conjunction with PID minimum / maximum scale (specified by J106 and
J107), you can specify 0 to 100 % of the PID command (±100 % for PID dancer control) in an easy-to-understand,
converted command format.
For details of operation, refer to Chapter 3 “3.3.5 Setting up PID commands from the keypad.”
