Fuji Electric FRENIC MEGA G2 Series - 1 ] Standard Specification; Specification

11.9 High Power Factor Power Supply Regeneration PWM Converters (RHC Series)
11-25
SELECTING PERIPHERAL EQUIPMENT
Chap 11
11.9.2 Specification
[ 1 ] Standard specification
MD (CT) specification (for medium overloads)
Three-phase 200 V input series (unit type)
Item
Specification
Type: RHC□-2EJ
30
37
45
55
75
90
Applicable inverter capacity
[kW]
30
37
45
55
75
90
Output
Continuous capacity
[kW]
36
44
53
65
88
103
Overload rating
Continuous rating of 150%-1 min
Voltage
320 to 355 VDC (varies based on input voltage) (*2)
Input power supply
Main power supply
Number of phases,
voltage, frequency
Three-phase three-wire system, 200 to 220 V/50 Hz󳞩
200 to 230 V/60 Hz (*1)
Control power
auxiliary input
Number of phases,
voltage, frequency
Single-phase 200 to 230 V, 50/60 Hz
Fan power auxiliary
input
Number of phases,
voltage, frequency
-
Single-phase 200 to 220 V/50 Hz，
200 to 230 V/60 Hz (*1)
Permissible
fluctuations
Voltage: -15 to +10%, frequency: +5 to -5%,
voltage interphase unbalance ratio: within 2% (*3)
Required power supply
capacity [kVA] (*6)
38
47
57
70
93
111
Carrier frequency [kHz]
7.5 to 15
(*4)
5 to 10
(*5)
Approximate weight [kg]
24
29
39
39
55
95
Protective construction
IP00 open type
(Note 1) The specifications are as shown above for function code F03 = 0 (MD (CT)).
(*1) Customer orders for 220 to 230 V/50 Hz models are accepted.
(*2) When the power supply voltage is 200 V, the output voltage is approximately 320 VDC, 343 VDC when 220 V, and 355
VDC when 230 V.
(*3) Interphase unbalance ratio (%) =
Max. voltage [V] - Min. voltage [V]
Three-phase average voltage
×67
(*4) When equipped with OPC-RHCE-TBSI-2, the carrier frequency with no transformer automatically becomes 7.5 kHz.
(*5) When equipped with OPC-RHCE-TBSI-2, the carrier frequency with no transformer automatically becomes 5 kHz.
(*6) Be sure to connect to a power supply with the above required power supply capacity or higher.
(If the power supply capacity is insufficient, the converter or inverter may suffer damage due to waveform distortion at the
power supply side.)
If a power supply boosted with a low-capacity transformer is used for the main circuit power supply, etc. for performing a
control panel sequence check in particular, there is a possibility that problems may occur. In cases such as this, open the
converter “RUN-CM”, and perform a sequence check of other parts without running the converter.
