5.3 Description of Function Codes 5.3.10 U codes (Customizable logic operation)
5-380
U00
U01 to U70
U71 to U80
U81 to U90
U91
U92 to U97
U100
U101 to U106
U107
U121 to U170
U171 to U180
U181 to U184
U185 to U188
U190 to U195
Customizable logic (Operation selection)
Customizable logic: Step 1 to 14 (Block selection, Input 1/2, Function 1/2)
Customizable logic: Output signal 1 to 10 (Output selection)
Customizable logic: Output signal 1 to 10 (Function selection)
Customizable logic: Customizable logic timer monitor (Step selection)
Customizable logic: Conversion factor
Customizable logic: Task process cycle setting
Customizable logic: Conversion operation point 1 (X, Y) to 3 (X, Y)
Customizable logic: Automatic calculation of coefficients
Customizable logic: User parameter 1 to 50
Customizable logic: Storage area 1 to 10
Customizable logic: Output signal 11 to 14 (Function selection)
Customizable logic: Output signal 11 to 14 (Output selection)
Customizable logic: Step 15 to 260 setting
 Customizable Logic (Operation selection) (U00)
U00 specifies whether to enable the sequence configured with the customizable logic function or disable it to run
the inverter only via its input terminals or others.
U00 data
Function
0
Disable
1
Enable (Customizable logic operation)
The ECL alarm occurs when changing U00 from 1 to 0 during operation.
 Customizable Logic (Mode Setting) (U01 to U70, U190 to U195)
In the customizable logic, the steps are categorized in the following three types:
[Input: digital] Block selection (U01, U06, U11, etc.) = 1 to 1999
Input 1 (digital)
Input 2 (digital)
Output (digital)
Time
setting
Logic circuit
General-
purpose timer
[Input: analog] Block selection (U01, U06, U11, etc.) = 2001 to 3999
Input 1 (analog)
Input 2 (analog)
Output (analog/digital)
Operation
circuit
[Input: digital, analog] Block selection (U01, U06, U11, etc.) = 4001 to 5999
Input 1 (analog)
Input 2 (digital)
Output (analog)
Operation
circuit
Logic circuit
