11.12 AC Reactors (ACRs)
11-69
SELECTING PERIPHERAL EQUIPMENT
Chap 11
Table 11.12-1 AC reactor (ACR) specifications (cont.)
Power
system
Standard
applicable
motor
(kW) [HP]
Inverter type
Specification
Reactor
type
Rated
current
(A)
Reactance (mΩ/phase)
Coil
resistance
(mΩ)
Generated
loss
(W)
50 Hz
60 Hz
Three-
phase
400 V
0.4 [1/2]
FRN0002G2□-4G
HHD
ACR4-0.75 A
2.5
1920
2300
-
5
0.75 [1]
FRN0003G2□-4G
10
1.5 [2]
FRN0004G2□-4G
ACR4-1.5 A
3.7
1160
1390
-
11
2.2 [3]
FRN0006G2□-4G
ACR4-2.2 A
5.5
851
1020
-
14
3.7 [5]
FRN0009G2□-4G
ACR4-3.7 A
9
512
615
-
17
5.5 [7.5]
FRN0018G2□-4G
HHD
ACR4-5.5 A
13
349
418
-
22
7.5 [10]
HND
ACR4-7.5 A
18
256
307
-
27
FRN0023G2□-4G
HHD
11 [15]
HND
ACR4-11A
24
183
219
-
40
FRN0031G2□-4G
HHD
15 [20]
HND
ACR4-15A
30
139
167
-
46
FRN0038G2□-4G
HHD
18.5 [25]
HND
ACR4-18.5 A
39
114
137
-
57
FRN0045G2□-4G
HHD
22 [30]
HND
ACR4-22A
45
95.8
115
-
62
FRN0060G2□-4G
HHD
30 [40]
HND
ACR4-37
100
41.7
50
2.73
38.9
FRN0075G2□-4G
HHD
37 [50]
HND
ACR4-37
100
41.7
50
2.73
55.7
FRN0091G2□-4G
HHD
45 [60]
HND
ACR4-55
135
30.8
37
1.61
50.2
FRN0112G2□-4G
HHD
55 [75]
HND
ACR4-55
135
30.8
37
1.61
70.7
FRN0150G2□-4G
HHD
75 [100]
HND
ACR4-75 *
160
25.8
31
1.16
65.3
FRN0180G2□-4G
HHD
90 [125]
HND
ACR4-110
250
16.7
20
0.523
42.2
FRN0216G2□-4G
HHD
110 [150]
HND
ACR4-110
250
16.7
20
0.523
60.3
FRN0260G2□-4G
HHD
132 [200]
HND
ACR4-132 *
270
20.8
25
0.741
119
FRN0325G2□-4G
HHD
160 [250]
HND
ACR4-220
561
10
12
0.236
56.4
FRN0377G2□-4G
HHD
200 [300]
HND
ACR4-220
561
10
12
0.236
90.4
FRN0432G2□-4G
HHD
220 [350]
HND
ACR4-220
561
10
12
0.236
107
FRN0520G2□-4G
HHD
250 [350]
HND
ACR4-280
825
6.67
8
0.144
96.4
280 [400]
108
FRN0650G2□-4G
HHD
315 [450]
HND
ACR4-355
825
6.67
8
0.144
194
FRN0740G2□-4G
HHD
355 [500]
FRN0650G2□-4G
HND
ACR4-355 *
825
6.67
8
0.144
245
FRN0740G2□-4G
FRN0960G2□-4G
HHD
400 [600]
FRN0740G2□-4G
HND
ACR4-450
950
6.67
8
0.136
380
FRN0960G2□-4G
FRN1040G2□-4G
HHD
450 [700]
FRN0960G2□-4G
HND
ACR4-450
950
6.67
8
0.136
380
FRN1040G2□-4G
500 [800]
FRN0960G2□-4G
HND
ACR4-530
1100
5.75
6.9
0.0824
340
FRN1040G2□-4G
FRN1170G2□-4G
HHD
560 [900]
FRN1040G2□-4G
HND
ACR4-630
1300
4.87
5.84
0.0713
422
FRN1170G2□-4G
630 [900]
ACR4-630
1300
4.87
5.84
0.0713
422
FRN1386G2□-4G
HHD
710 [1000]
HND
-
-
-
-
-
-
* Perform fan cooling (3 m/s or more).
(Note 1) □ is replaced by a letter of the alphabet indicating the inverter type.
□
S (basic type), E (type with built-in EMC filter)
(Note 2) Generated losses listed in the above tables are approximate values that are calculated according to the
following conditions:
• The power supply is 200 V or 400 V 50 Hz with 0% interphase voltage unbalance ratio.
• The capacity of the power supply used is the larger of either 500 kVA or 10 times the rated capacity
of the inverter.
• The motor is a 4-pole standard model at full load (100%).
