7.4. Piping data
Stainless steel pipe for pipe arrangement (JIS G3459-2012)
Nominal
diameter
Outer
diameter
mm
Thickness
Schedule
5S
Schedule
10S
Schedule
20S
Schedule
40
Schedule
80
Schedule
120
Schedule
160
A B
Thickness
mm
Thickness
mm
Thickness
mm
Thickness
mm
Thickness
mm
Thickness
mm
Thickness
mm
15 1/2 21.7 1.65 2.1 2.5 2.8 3.7 - 4.7
20 3/4 27.2 1.65 2.1 2.5 2.9 3.9 - 5.5
25 1 34.0 1.65 2.8 3.0 3.4 4.5 - 6.4
32 1 1/4 42.7 1.65 2.8 3.0 3.6 4.9 - 6.4
40 1 1/2 48.6 1.65 2.8 3.0 3.7 5.1 - 7.1
50 2 60.5 1.65 2.8 3.5 3.9 5.5 - 8.7
65 2 1/2 76.3 2.1 3.0 3.5 5.2 7.0 - 9.5
80 3 89.1 2.1 3.0 4.0 5.5 7.6 - 11.1
90 3 1/2 101.6 2.1 3.0 4.0 5.7 8.1 - 12.7
100 4 114.3 2.1 3.0 4.0 6.0 8.6 11.1 13.5
125 5 139.8 2.8 3.4 5.0 6.6 9.5 12.7 15.9
150 6 165.2 2.8 3.4 5.0 7.1 11.0 14.3 18.2
200 8 216.3 2.8 4.0 6.5 8.2 12.7 18.2 23.0
250 10 267.4 3.4 4.0 6.5 9.3 15.1 21.4 28.6
300 12 318.5 4.0 4.5 6.5 10.3 17.4 25.4 33.3
350 14 355.6 - - - 11.1 19.0 27.8 35.7
400 16 406.4 - - - 12.7 21.4 30.9 40.5
450 18 457.2 - - - 14.3 23.8 34.9 45.2
500 20 508.0 - - - 15.1 26.2 38.1 50.0
550 22 558.8 - - - 15.9 28.6 41.3 54.0
600 24 609.6 - - - 17.5 31.0 46.0 59.5
650 26 660.4 - - - 18.9 34.0 49.1 64.2
Polyethylene pipe for city water (JIS K6762-2004)
Nominal
diameter
(mm)
Outer
diameter
(mm)
1st type (Soft pipe) 2nd type (Hard pipe)
Thickness
(mm)
Weight
(kg/m)
Thickness
(mm)
Weight
(kg/m)
13 21.5 3.5 0.184 2.5 0.143
20 27.0 4.0 0.269 3.0 0.217
25 34.0 5.0 0.423 3.5 0.322
30 42.0 5.6 0.595 4.0 0.458
40 48.0 6.5 0.788 4.5 0.590
50 60.0 8.0 1.216 5.0 0.829
Galvanized steel pipe for city water SGPW (JIS G3442-2010)
How to call pipe
Outer diameter
(mm)
Thickness
(mm)
(A) (B)
15 1/2 21.7 2.8
20 3/4 27.2 2.8
25 1 34.0 3.2
32 1 1/4 42.7 3.5
40 1 1/2 48.6 3.5
50 2 60.5 3.8
65 2 1/2 76.3 4.2
80 3 89.1 4.2
90 3 1/2 101.6 4.2
100 4 114.3 4.5
125 5 139.8 4.5
150 6 165.2 5.0
200 8 216.3 5.8
250 10 267.4 6.6
300
350
400
450
500
12
14
16
18
20
318.5
355.6
406.4
457.2
508.0
6.9
7.9
7.9
7.9
7.9
