4.10.5.6. How to validate the output at the minus direction action
Description

Select a contact output as DO1 and/or DO2 when the flow is in reverse direction.
For actual keying, refer to the typical operation indicated below. Set the protection to OFF beforehand. (See Section 4.4.1.)
Operation
(example)
Set the DO1 output to “-:FLOW DIRECTION”.
Also, set the contact to “ACTIVE ON”.
Key operation Description Display
▼
Press the key twice to display “OUTPUT SETUP”.
OUTPUT SETUP
ENT
▼
Press the
ENT
key once to display “ZERO ADJUSTMENT”.
ZERO ADJUSTMENT
SET ZERO
▼
Press the key for 6 times to display “DO1 OUT”.
* Press the
key again to display “DO2 OUT”.
DO1 OUT
NOT USED
ENT
▼
Press the
ENT
key once to blink the cursor.
DO1 OUT
NOT USED
▼
Press the key for 9 times to display “-:FLOW DIRECTION” on the
2nd line.
DO1 OUT
-:FLOW DIRECTION
ENT
▼
▼
▼
▼
Press the
ENT
key once to register “-:FLOW DIRECTION”.
DO1 OUT

COMPLETE

↓
――― “-:FLOW DIRECTION” has been registered. ―――
STATUS OUT
CONTACT ACTION
ENT
▼
Press the
ENT
key once to display “CONTACT ACTION”.
CONTACT ACTION
ACTIVE ON
ENT
▼
▼
▼
▼
Press the
ENT
key once to register “ACTIVE ON”(normally off).
* To select normally on, press the
key.
CONTACT ACTION

COMPLETE

↓
――― “ACTIVE ON” has been registered. ―――
STATUS OUT
CONTACT ACTION
ESC
Press the
ESC
key twice and then press the key for 3 times to enter
the measurement mode.
0.000 %
0.000 m3
