-55-
4.10.5. Setting the DO output
4.10.5.1. How to validate outputting the FULL SCALE 2
Description

Select a contact output as DO1 and/or DO2 at FULL SCALE2 measurement status.
For actual keying, refer to the typical operation indicated below. Set the protection to OFF beforehand. (See Section 4.4.1.)
Operation
(example)
Set the DO1 output to “FULL SCALE2”.
Also, set the contact to “ACTIVE ON”.
Key operation Description Display
▼
Press the key twice to display “OUTPUT SETUP”.
OUTPUT SETUP
ENT
▼
Press the
ENT
key once to display “ZERO ADJUSTMENT”.
ZERO ADJUSTMENT
SET ZERO
▼
Press the key for 6 times to display “DO1 OUT”.
* Press the
key again to display “DO2 OUT”.
DO1 OUT
NOT USED
ENT
▼
Press the
ENT
key once to blink the cursor.
DO1 OUT
NOT USED
▼
Press the key for 3 times to display “FULL SCALE2” on the 2nd line.
DO1 OUT
FULL SCALE2
ENT
▼
▼
▼
▼
Press the
ENT
key once to register “FULL SCALE2”.
DO1 OUT

COMPLETE

↓
――― “FULL SCALE2” has been registered. ―――
STATUS OUT
CONTACT ACTION
ENT
▼
Press the
ENT
key once to display “CONTACT ACTION”.
CONTACT ACTION
ACTIVE ON
ENT
▼
▼
▼
▼
Press the
ENT
key once to register “ACTIVE ON”(normally off).
* To select normally on, press the
key.
CONTACT ACTION

COMPLETE

↓
――― ACTIVE ON has been registered. ―――
STATUS OUT
CONTACT ACTION
ESC
Press the
ESC
key twice and then press the key for 3 times to enter
the measurement mode.
0.000 %
0.000 m3
