Fuji Electric Time Delta-C FSV-2 User Manual

-67-
4.11.4. How to check the status output
Description

Check the status output.
Setting content ON: Close the contact.
OFF: Open the contact.

This operation sets DO1 and DO2 the same contact action.

Before operation, check whether DO output testing is permitted.
For actual keying, refer to the typical operation indicated below. Set the protection to OFF beforehand. (See Section 4.4.1.)
Operation
(example)
Check the contact action.
Key operation Description Display
▼
Press the key for 4 times to display “MAINTENANCE MODE”.
MAINTENANCE MODE
ENT
▼
Press the
ENT
key once to display “RAS INFORMATION”.
RAS INFORMATION
000000000000000
▼
Press the key for 4 times to display “STATUS”.
DO CHECK
OFF
ENT
▼
Press the
ENT
key once to blink the cursor.
Note) Contact output is displayed at this time.
“OFF” is given at right.
DO CHECK
OFF
▼
Press the key once, and select “ON”.
DO CHECK
ON
ENT
▼
▼
▼
▼
Press the
ENT
key once to register “ON”.
DO CHECK

COMPLETE

↓
――― “ON” has been registered. ―――
* Check the contact output “ON”.
DO CHECK
ON
▼
Press the key once, and select “OFF”.
DO CHECK
OFF
ENT
▼
▼
▼
▼
Press the
ENT
key once to register “OFF”.
DO CHECK

COMPLETE

↓
――― “OFF” has been registered. ―――
* Check the contact output “OFF”.
DO CHECK
OFF
ESC
▼
Press the
ESC
key once to stop the cursor from blinking.
* It returns to contact output at the normal measurement status.
DO CHECK
OFF
ESC
Press the
ESC
key once and then press the key once to enter the
measurement mode.
0.000 %
0.000 m3
CAUTION
