4.8.2. How to set the flow rate unit
Description

Select the unit of flow rate.

Metric system
Flow rate ········ L/s, L/min, L/h, L/d, kL/d, ML/d, m
3
/s, m
3
/min, m
3
/h (factory set), m
3
/d, km
3
/d, Mm
3
/d, BBL/s, BBL/min, BBL/h, BBL/d,
kBBL/d, MBBL/d
<Note> First, set the unit system (metric) according to Section 4.8.1.
For actual keying, refer to the typical operation indicated below. Set the protection to OFF beforehand. (See Section 4.4.1.)
Operation
(example)
Set a flow rate unit to “L/min”.
Key operation Description Display
▼
Press the key for 3 times to display “MEASURE SETUP”.
MEASURE SETUP
ENT
▼
Press the
ENT
key once to display “SYSTEM UNIT”.
SYSTEM UNIT
METRIC
▼
Press the key once to display “FLOW UNIT”.
FLOW UNIT
m3/h
ENT
▼
Press the
ENT
key once to blink the cursor.
FLOW UNIT
m3/h
▼
Press the key several times to display “L/min”.
FLOW UNIT
L/min
ENT
▼
▼
▼
▼
Press the
ENT
key once to register.
FLOW UNIT

COMPLETE

↓
――― “L/min” has been registered. ―――
FLOW UNIT
L/min
ESC
Press the
ESC
key once and the key twice to return to the
measurement mode.
0.000 m/s
0.000 L/min
