Fuji Electric Time Delta-C FSV-2 User Manual

-89-
6.5.1.3. Checking the RAS information
When the red LED lights up, check the error contents according to the RAS information.
Key operation Description Display
▼
Press the key for 4 times to display “MAINTENANCE MODE”.
MAINTENANCE MODE
ENT
Press the key once to display “RAS INFORMATION”.
RAS INFORMATION
0000000000000000
If the display is abnormal, 1 is set.
Move the cursor to 1 by the
key,
and press the
ENT
key to display the
status contents. Pressing the
ENT
key again displays the troubleshooting.
Configuration of the RAS information
               
Comparison of error with LED
E1: Device error 1

E1: Device error 2

Lit in red when set at “1”.
E2: Data collection error

E2: Window scanning

E2: No received signal

E2: Received signal error

E2: Received signal range over

E2: Calculation failure

Backup
Backup
Backup
Backup
Backup
Backup
E4: Range over

Lit in green
Backup
RAS information Status Troubleshooting
E1: Device error 1 Backup memory failure See “6.5.7. Remedying a hardware fault”.
E1: Device error 2 Abnormality of measuring circuit Turn the power off then on again. If the
instrument does not recover properly, refer to
“6.5.7. Remedying a hardware fault”.
E2: Data collection error Ultrasonic send/receive signals cannot be
collected.
E2: Window scanning The ultrasonic receiving signal waveform is
being detected.
Move the mounting position of the detector,
and remount the detector.
Repair or replace the signal cable.
Transmitter circuit failure or detector failure

See “6.5.7. Remedying a hardware fault”.
E2: No received signal No ultrasonic receiving signal waveform
E2: Received signal error The status of received waveform is poor. Check the air bubbles or foreign objects.
Check the receive sensitivity.

Move the mounting position of the
detector, and remount the detector.
E2: Received signal
range over
Receiving signal waveform is outside the
appropriate range.
Check the piping data.
Check the detector mounting dimensions.
E2: Calculation failure The value of detected measurement data is
abnormal.
Check the piping data.
Check the receive sensitivity.

Move the mounting position of the
detector, and remount the detector.
E4: Range over Analog output and total output exceed the
range.
Check the range data and the totalize
setting.
Correspondence between DO output and Alarm
“
All” : Alarm is issued at occurrence of E1 or E2. [Burnout timer is enabled]
“
Device error” : Alarm is issued at occurrence of E1. [Burnout timer is disabled]
“
Process error” : Alarm is issued at occurrence of E2. [Burnout timer is enabled]
Burnout timer is to set a time between error occurrence and contact output.
