Basic Operation 41
Rear View
Automatic Document Feeder (ADF)
1 Registration Roller 2 OPC Drum
3 Levers 4 ADF Cover
5 Ethernet Port 6 USB Port
7 Paper Chute 8 Transfer Roller
9 Power Connector 10 Rear Cover Handle
11 Rear Cover 12 Phone Connector
13 Wall Jack Connector
1 ADF Cover
2 Document Guides
3 ADF Glass
4 Document Glass
5 Document Cover
6 Document Feeder Tray
7
1
23 4 56
8 9 10 12 1311
12 3
5
4
6
