Range Description
Range: 0 to 510 mm, in 2 mm increments, Start <
End
HINT
● When both [Start] and [End] are set to "0", multifeed detection is performed for the whole area
regardless of whether it is enabled or disabled.
● To disable multifeed detection for the whole document, select [Disable] and set the start position to "0"
and the end position to be equal to or longer than the document length.
● If the start position is set larger than the document length: with [Disable], the whole range covering the
entire document length will be checked; with [Enable], the multifeed detection will be disabled.
● To detect multifeeds, the detection range must be at least 8 mm in length.
Configure the settings so that the value of the end position minus the start position is 6 mm or more.
● You can also set the start position and the end position by the following methods:
- Create a square or rectangle to indicate the detection range by dragging your mouse pointer on the
displayed image in the dialog box.
- Drag the handle for the detection range to change the start and end positions using the mouse
pointer on the displayed image in the dialog box.
Example 1:
Setting details are as follows.
● Specified position: Left
Selected range = Disable, Start = 50 mm, End = 200 mm
● Specified position: Middle
Selected range = Enable, Start = 50 mm, End = 200 mm
● Specified position: Right
