CHAPTER 4
ETSI Configuration
Installing Power and Ground Cables
FNC-7500-0061-200
Issue 1, May 2009
FLASHWAVE 7500 Release 6.1
Equipment Installation
4-68
Fujitsu and Fujitsu Customer Use Only
9 Connect both ends of cable GB of the power harness as follows:
a. Identify lug GB in the power harness (see Figure 4-44 [p. 4-63]) and connect it to shelf
terminal GB (see Figure 4-47 [p. 4-65]).
b. Connect the other end of the same cable to PDP terminal B1-1 +RTN (see Figure 4-45
[p. 4-64]).
10 Connect both ends of cable MA of the power harness as follows:
a. Identify lug MA in the power harness (see Figure 4-44 [p. 4-63]) and connect it to shelf
terminal MAIN A (see Figure 4-47 [p. 4-65]).
b. Connect the other end of the same cable to PDP terminal A1-1 -BATT (see Figure 4-45
[p. 4-64]).
11 Connect both ends of cable MB of the power harness as follows:
a. Identify lug MB in the power harness (see Figure 4-44 [p. 4-63]) and connect it to shelf
terminal MAIN B (Figure 4-47 [p. 4-65]).
b. Connect the other end of the same cable to PDP terminal B1-1 -BATT (see Figure 4-45
[p. 4-64]).
12 Connect both ends of cable FGND of the power harness as follows:
a. Identify lug FGND in the power harness (see Figure 4-44 [p. 4-63]) and connect it to
shelf terminal FG (see Figure 4-47 [p. 4-65]).
b. Connect the other end of the same cable to the equipment rack frame ground.
13 Replace the plastic covers over the SIA terminal strips.
Install Shelf Power Harnesses A2 and B2
14 Is a shelf to be connected to buses A2 and B2?
If YES:
Go to Step 15 [p. 4-69].
If NO:
Go to Step 24 [p. 4-70].
