4-6 SPARC Enterprise Mx000 Servers XSCF User’s Guide • January 2012
The showenvironment power and showenvironment air commands do not
include the information of External I/O Expansion Unit and peripheral I/O device.
Also, the M4000/M5000/M8000/M9000 servers do not indicate power consumption
by showenvironment command. For a power consumption value of the
M4000/M5000/M8000/M9000 servers, see the SPARC Enterprise M4000/M5000
Servers Site Planning Guide or the SPARC Enterprise M8000/M9000 Servers Site
Planning Guide.
For details of the showenvironment(8) command, see the XSCF Reference Manual
and man page. For the installation of server, see the Site Planning Guide for your
server.
Note – To obtain the data of exhaust air using the SNMP agent function, install the
latest XSCF extension MIB definition file to the SNMP manager. For details on
obtaining the XSCF extension MIB definition file, see the Product Notes for your
server or download site for firmware.
Note – The amount of power consumption and exhaust air may not be indicated
correctly in the MIB information, in the showenvironment power,
showenvironment air commands output, and on the XSCF Web in the following
cases; and you should wait for one minute and check the value again.
- During the server powering on or powering off, or for a while after the power-on
or power-off complete
- During the active replacement of power supply unit, or for a while after the active
replacement complete
4.1.2 Display Server Configuration/Status Information
■ Command operation
● Use the showhardconf(8) command to check the status of a device.
The status information of each device is as below.
XSCF> showhardconf
SPARC Enterprise xxxx;
+ Serial:PP20605005; Operator_Panel_Switch:Locked;
+ Power_Supply_System:Single; SCF-ID:XSCF#0;
+ System_Power:On; System_Phase:Cabinet Power On;
Domain#0 Domain_Status:Powered Off;
MBU_B Status:Normal; Ver:0101h; Serial:7867000282 ;
:
To Next Page
