9. MAINTENANCE, TROUBLESHOOTING
9-6
9.4 System Status Monitor
The system status monitor, which is always displayed, provides date, time,
equipment status and navigation data.
File Edit Transmit EGC Reports Logs Options Setup Position StopAlarm
Date
Time
Position
Waypoint
Course 345.5 DEG
Speed 10.2 KTS
Current NCS
Current Channel
Current TDM
MES Status
GPS Status
DCE Memory
02-02-25
01:32 (UTC)
LAT 34:30.00N
LON 135:00.00E
LAT
LON
344 (IOR) LOGOUT
NCS CC
NCS CC
Idle
****
32818 Bytes free
IMN:
BBER
C/N
Send Level
Rx AGC Level
REF Offset Freq
Synthe Local
VCXO Control 131
Antenna Power Supply
Water Temperature
Water Current
Direction
Speed
Depth
443156710
000
OK ( 0 dB)
OK ( 0)
OK (254)
OK ( 0 Hz)
OK
OK
Current State: IDLE
DCE F15 Ver. ##
Retuning
NCS: IOR LOGOUT LAT: 34:30.00N
LON: 135:00.00E
02-02-25 01:32 (UTC)
68.2 DEG
232 DEG
1.9 KTS
##: Program Version No. of RF CON Board
System status monitor display
Interpreting the system status monitor
Date: Current date
Time: Current time
Position: Own ship’s L/L position (either manual entry or
automatic input by navigator)
Waypoint: L/L position of destination waypoint set on navigator
Course: Course
Speed: Ship’s speed
Current NCS: NCS your vessel is logged in with
Current Channel: Channel in use
Current TDM: Channel TDM
MES Status: Operational status of MES
GPS Status: Receiving signal status from GPS receiver.
CST: Cold Start
ACK: Acquired; Almanac data acquired
IMP: Impossible; cannot receive GPS signal
INT: Interrupted; object interfering with reception
of GPS signal
ALM: Receiving the almanac
2D, 3D: Position-fixing method by 2D or 3D
