Furuno FELCOM 15 Operator's Manual

1. OPERATIONAL OVERVIEW
1-3
1.2 Keyboard
The FELCOM 15 is almost 100% keyboard controlled. Operation is carried out
with the function keys, numbered F1-F10 at the top of the keyboard. The figure
below shows keyboard layout.
~
`
2
1
345
67890 - =
_+)* ( 9*87 ^& % $#@!
QWERTYUIOP
[
]
{}
\
|
ASDF GHJ KL:+
;
"
'
Tab
Caps Lock
ZXCVBNM<> ?/
/
.
,
123
456
0Shift
Fn
Ctrl Alt
Alt
Ctrl
Home
End PgDn
PgUp
Shift
Enter
Backspace
Esc
F1
F2 F3
F4
F5 F6
F7
F8
F9 F10
Num
Lock
Prt Sc
SysRq
Scroll
Lock
Pause
Break
Insert Delete
C
File
Edit
Transmit
EGC
Reports
Logs
Options
Setup
StopAlarm
Position
Function
Keys
Keyboard
1.2.1 Key description
Esc Cancels key input and returns to previous display
screen.
F1-F10 These are the function keys, and they choose
menus.
Backspace Deletes the character to the left of the cursor.
Insert Works the same as “paste.” See “Copying and
pasting text” in paragraph 3.2.4.
Delete Deletes the character selected with the cursor.
Home Moves the cursor to the top of the message being
edited.
End Moves the cursor to the bottom of the message
being edited.
PgUp Goes to the previous page of the edit screen.
PgDn Goes to the next page of the edit screen.
[↑], [↓], [←], [→] Control the cursor.
Enter Registers key input; inserts carriage return in TX
message.
Shift Chooses upper or lower case alphabet. Press and
hold down the key and then press the [Caps Lock] to
get upper or lower case alphabet. Note that only
upper case alphabet are used in telex.
Alt Executes the shortcut key operation when combined
with an alphabet key. See paragraph 1.2.2.
