1. OPERATIONAL OVERVIEW
1-9
1.5.1 Display indications
The display is divided in three sections:
1) The function menu area
2) The working area
3) The operating status area
File Edit Transmit EGC Reports Logs Options Setup Position StopAlarm
(1) (2)
(3)
(4a)
(4b)
(5)
(6) (7)
(8)
(9)
(10)
(10)
2) WORKING AREA
1) Function
Menu
3) Operating
Status
Location of display indications
Below are the indications and meanings of the items in parentheses in the
illustration above.
(1) Distress alert information message
No display (no distress alert)
Sending Distress Alert
Sending Distress Alert Test
Distress Acknowledgement Received
Distress Message Call Activated
Distress Message Call Acknowledged
Distress Button Test Mode
(2) Communication network mode
No display Normal operation
Restoration Mode Problem at NCS
(Flashing)
Restoration Mode Previously designated LES is transmitting the
(Reverse video) NCS common channel signal.
