26
4.3.2.8 PowerUp
After setting Powerup motion, the camera will perform the configured motion after it is power
on.
Preparation
You have configured the PTZ motions, including preset, scan, tour, or pattern.
Procedure
Step 1 Select Setting > PTZ settings > Function > PowerUp.
The PowerUp interface is displayed. See Figure 4-15.
Figure 4-15 PowerUp
Step 2 Select the Enable check box to enable the power up function.
Step 3 Select the power up motion.
When you select Auto, the system will perform the last motion that is executed for
more than 20 s before power-off.
Step 4 Click OK.
4.3.2.9 PTZ Limit
After setting PTZ limit, the camera can only rotate within the configured area.
Step 1 Select Setting > PTZ settings > Function > PTZ Limit.
The PTZ Limit interface is displayed. See Figure 4-16.
To Next Page
